The Mode 4 DC Fast Charger series covers 60kW to 180kW output, letting operators match infrastructure investment with local grid capacity and vehicle demand. A modular power conversion architecture means that maintenance work or individual module failures do not shut down the station, keeping service available in high-traffic commercial zones.
Compliance with both OCPP 1.6J and OCPP 2.0.1 ensures smooth integration with any Charge Point Management System (CPMS). Dual-protocol support enables dynamic load balancing and secure certificate-based communication. The hardware is ready for ISO 15118 Plug & Charge, removing manual authentication for drivers at public charging plazas and retail hubs.
The station uses an IP54-rated enclosure with corrosion protection for outdoor deployment. Output spans 150V-1000V DC, covering current passenger EVs and light commercial vehicles. A 7-inch sunlight-readable interface and multi-standard connector options (CCS2/CHAeMO/GBT) are included as standard.
| Category | 60kW Model | 120kW Model | 180kW Model |
|---|---|---|---|
| Charging Mode | Mode 4 | Mode 4 | Mode 4 |
| Output Voltage | 150V - 1000V DC | 150V - 1000V DC | 150V - 1000V DC |
| Protocol | OCPP 2.0.1 / 1.6J | OCPP 2.0.1 / 1.6J | OCPP 2.0.1 / 1.6J |
| Efficiency | ≥ 96% | ≥ 96% | ≥ 96% |
| Protection | IP54 / IK10 | IP54 / IK10 | IP54 / IK10 |
| Interface | 7" Touch Screen | 7" Touch Screen | 7" Touch Screen |
| Connectors | CCS2 / CHAdeMO / GBT | CCS2 / CHAdeMO / GBT | CCS2 / CHAdeMO / GBT |
The charger features dual compliance, supporting both OCPP 1.6J and the newer OCPP 2.0.1 standards for robust communication and security.
Yes. With an output voltage range spanning 150V to 1000V DC, it is optimized for high-voltage architectures, including 800V luxury and commercial EVs.
The power conversion system uses independent internal modules. If one module experiences an issue, the station continues to operate at reduced capacity, lowering maintenance shutdown times.
Yes. The system is designed to support ISO 15118 Plug & Charge standards, allowing automatic vehicle authorization and payment without manual apps or RFID cards.
It comes with an IP54-rated, corrosion-protected enclosure and IK10 impact resistance, making it highly durable for outdoor deployments in commercial spaces.
The charger is equipped with standard CCS2, CHAdeMO, and GBT connector configurations to serve diverse electric vehicles globally.
