| Car brand | Model | Support |
|---|---|---|
| Nissan | Leaf(21 kwh) | Yes |
| E-NV200(21 kwh) | Yes | |
| Evalia(21 kwh) | Yes | |
| Mitsubishi | Outlander(10 kwh) | Yes |
| Imiev/C-Zero/ION(14.7kwh) | Yes | |
| Toyota | Mirai(26 kwh) | Yes |
| Honda | Fit (18 kwh) | Yes |
| Input Voltage range | 200-420Vdc |
| Power range | 0-500VA(4KW) |
| Current range(DC) | 0-20A |
| Current range(AC bypass) | 0-20A |
| Efficiency(max) | 95% |
| Protection | |
| Input OCP OCP | Voltage & Frequency Window, (DC Injection TBD)(external fuse) |
| Over Temperature | 70°C at main Heatsink. Output Power derating at > 50°C temperature |
| Isolation Monitor Device | Disconnect @ < 500kD |
| General | |
| Protection Class(isolation) | Class1 Transformer design |
| Cooling | Fan cooled |
| IP protection class | IP20 |
| Working Temp. & Humi. | 20~50°C, 90% Non Condensing |
| Dimension & Weight | 560X223X604mm, 25.35kg >100,000 hours @ 25°C |
| Safety & EMC CE | |
| Safety | EN60950 |
| Emission | EN55011, class A (optional B) |
| Immunity | EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-11 |
To use a V2H (Vehicle-to-Home) charging station, you need a compatible vehicle and a bidirectional charging system with an associated meter and transfer switch. Plug your vehicle into the V2H charging station, which intelligently distributes power to the vehicle, your home, or both. During a power outage, the system isolates itself from the grid and uses the vehicle's battery to power your home.
V2H technology enables electric vehicle owners to integrate their vehicles into their home energy management system. The vehicle's battery acts as a backup power source, enhancing energy resiliency and self-sufficiency during emergencies.
