| Electrical Parameter | 32A Max | 40A 50A Max |
| One phase input: nominal voltage 1x230VAC 50-60 Hz | ||
| 7 kW at 1x230VAC | 11 kW 12KW at 1x 230 VAC | |
| Input Cord | Hard wired by licensed electrician | |
| Output Cable & Connector | 16.4FT/5.0 m cable (26.2FT/8.0m optional) | |
| IEC62196-2 standard compliance | ||
| Smart Grid Connectivity | Built-in Wi-Fi (Optional)(802.11 b/g/n/2.4GHz) / Bluetooth Connectivity | |
| Firmware | Over-the-air (OTA) upgradeable firmware | |
| Environmental Parameter | Dynamic LED lights show charging status: standby, charging, fault, network connectivity | |
| 4.3" LCD Screen | ||
| Protection Class IP65: Weatherproof, dust-tight | ||
| IK08: Resistant polycarbonate case | ||
| Quick-release wall mounting bracket included | ||
| Operating Temperature: -22°F to 122°F (-30°C to 50°C) | ||
| Dimension | Main enclosure: 9.7in x 12.8in x 3.8in (300mm x 160mm x 120mm) | |
| Codes & Standards | IEC 61851-1 / IEC61851-21-2 / IEC62196-2 compliance, OCPP 1.6 | |
| Certification | FCC ETL CE compliance | |
| Energy Management | Home power balancing (Optional) | |
| RFID / 4G / Socket | Optional | |
| Warranty | 2 years limited product warranty | |
