| Item | 180kW DC Charger | 240kW DC Charger | 300kW DC Charger |
| Input | Input Voltage | 3-phase 400V ±15% AC | |
| Input Voltage Type | TN-S (Three Phase Five Wire) | ||
| Working Frequency | 45~65Hz | ||
| Power Factor | ≥0.99 | ||
| Efficiency | ≥94% | ||
| Output | Rated Voltage | DC - CHAdeMO 500Vdc; CCS 1000Vdc; GBT 1000Vdc; AC - Type-2 400V; GBT 400V | |
| Max. Output Current | DC - CHAdeMO 125A; CCS 200A; GBT 250A; | AC - Type-2 63A; GBT 32A | |
| Interface | Display | 8'' LCD Touchscreen | |
| Language | Chinese, English, French, German, Spanish, Russian, etc. | ||
| Payment | Mobile APP/RFID/POS | ||
| Communication | Network Connection | 4G(GSM or CDMA)/Ethernet | |
| Communication Protocols | OCPP1.6J or OCPP2.0 | ||
| Working Environment | Working Temperature | -30°C ~ +55°C | |
| Storage Temperature | -35°C ~ +55°C | ||
| Operating Humidity | ≤95% Non-Condensing | ||
| Protection | IP54 | ||
| Acoustic Noise | <60dB | ||
| Cooling Method | Forced Air-Cooling | ||
| Mechanical | Dimension(W x D x H) | 700*1900*650mm | |
| No. of Charging Cable | Single | Dual | |
| Cable Length | 5m or 7m | ||
| Regulation | Certificate | CE/IEC61851-1/IEC61851-23/IEC61851-21-2 | |
Simultaneously charging up to 3 EVs with ultra-fast performance.
Revolutionary 300kW Charging: The 300kW electric vehicle charging station provides a faster charging experience than currently possible. This highly efficient station can significantly boost an EV's battery in just 20 minutes, making it ideal for commercial and public locations.
Speed Comparison: Charging from 10% to 80% on a 300kW charger takes approximately 16 minutes, compared to 22 minutes on a 150kW charger. The ultra-fast DC charging technology significantly reduces downtime for drivers.
Introducing the high-power charger that delivers ultra-fast DC charging with an output of up to 350 kW. This charger is designed to significantly reduce charging times, giving your electric vehicle a massive increase in range in just minutes.
Compatible High-Speed EVs: The Hyundai IONIQ 5, Kia EV6, Porsche Taycan, Lucid Air, and Tesla Model S Plaid are among the fastest-charging cars currently available, capable of receiving high-power charges from 250 kW and up to 350 kW chargers.
