| Electrical Parameter | 32A Max | 40A 48A Max |
| One phase input: nominal voltage 1×230VAC 50-60 Hz | ||
| 7.2 kW at 1x240VAC | 9.6 kW / 12KW at 1x 240 VAC | |
| Input Cord | Hard wired by licensed electrician | |
| Output Cable & Connector | 16.4FT/5.0 m cable (26.2FT/8.0m optional) | |
| SAE J1772 standard compliance | ||
| Smart Grid Connectivity | Built-in Wi-Fi (Optional)(802.11 b/g/n/2.4GHz) / Bluetooth Connectivity | |
| Firmware | Over-the-air (OTA) upgradeable firmware | |
| Environmental Parameter | Dynamic LED lights show charging status (standby, charging, fault, network) | |
| 4.3" - 7.0" LCD Screen | ||
| Protection Class IP65: Weatherproof, dust-tight | ||
| IK08: Resistant polycarbonate case | ||
| Quick-release wall mounting bracket included | ||
| Operating Temperature: -22°F to 122°F (-30°C to 50°C) | ||
| Dimension | Main enclosure: 9.7in x 12.8in x 3.8in (300mm x 160mm x 120mm) | |
| Codes & Standards | IEC 61851-1 / IEC 61851-21-2 / IEC 62196-2 compliance, OCPP 1.6 | |
| Certification | FCC ETL CE compliance | |
| Energy Management | Home power balancing (Optional) | |
| RFID / 4G / Socket | Optional Module Support | |
| Warranty | 2 years limited product warranty | |
Perfect for homeowners who own a single electric vehicle and want a reliable and convenient way to charge at home. Compact design and high power output.
Installed at offices or factories to provide employees with a convenient way to charge their electric vehicles while they work.
Suitable for roadside installation or public parking lots, providing owners with convenient charging options while out and about.
High charging power (7kW/11KW/12KW) helps businesses quickly charge electric vehicle fleets, keeping operations productive.
A true artwork designed to improve the charging experience with a breakthrough in traditional appearance.
LED light shows charging status via color changes, using a breathing light effect to avoid direct glare.
User-friendly design for effortless installation, maintenance, and daily operation.
Uses SAE J1772/Type 2 connectors, compatible with every EV currently on the market.
A: The charger supports multiple configurations, ranging from 7.2 kW (32A) up to 12 kW (48A) depending on your electrical setup.
A: Yes, it features an IP65 protection rating, making it weatherproof and dust-tight, suitable for both indoor and outdoor environments.
A: Yes, the charger is equipped with Over-the-air (OTA) firmware upgrade capabilities to ensure you always have the latest features.
A: The charger uses the SAE J1772 standard (Type 2 available), making it compatible with all standard electric vehicles on the market.
A: It comes with built-in Wi-Fi and Bluetooth. Optional 4G modules and OCPP 1.6 compliance are also supported for advanced networking.
A: We provide a 2-year limited product warranty covering manufacturing defects and hardware performance.
