1 / 5
| Electrical Parameter | 32A Max | 40A 50A Max |
| Input Voltage | One phase input: nominal voltage 1×230VAC 50-60 Hz | |
| Charging Power | 7 kW at 1x230VAC | 11 kW 12KW at 1x 230 VAC |
| Input Cord | Hard wired by licensed electrician | |
| Output Cable & Connector | 16.4FT/5.0 m cable (26.2FT/8.0m optional) | |
| IEC62196-2 standard compliance | ||
| Smart Grid Connectivity | Built-in Wi-Fi (Optional)(802.11 b/g/n/2.4GHz) / Bluetooth Connectivity | |
| Firmware | Over-the-air (OTA) upgradeable firmware | |
| Status Indication | Dynamic LED lights show status: standby, charging in progress, fault indicator, network connectivity | |
| Display | 4.3" LCD Screen | |
| Protection Class | IP65: Weatherproof, dust-tight | |
| Impact Resistance | IK08: Resistant polycarbonate case | |
| Mounting | Quick-release wall mounting bracket included | |
| Operating Temperature | -22°F to 122°F (-30°C to 50°C) | |
| Dimension | Main enclosure: 9.7in x 12.8in x 3.8in (300mm × 160mm × 120mm) | |
| Codes & Standards | IEC 61851-1 / IEC61851-21-2 / IEC62196-2 compliance, OCPP 1.6 | |
| Certification | FCC ETL CE compliance | |
| Energy Management | Home power balancing (Optional) | |
| RFID / 4G / Socket | Optional configurations available | |
| Warranty | 2 years limited product warranty | |
This charger is perfect for homeowners who own a single electric vehicle and want a reliable and convenient way to charge it at home. Its compact design and high charging power make it an excellent choice for home use.
Can be installed at workplaces, such as offices or factories, to provide employees with a convenient way to charge their electric vehicles while they work.
Suitable for public areas, such as roadside stations or public parking lots, providing EV owners with convenient options while they are out and about.
Businesses operating EV fleets benefit from high charging power (7kW/11kW/12kW), quickly returning vehicles to the road to maintain productivity.
Overall, this single gun smart AC EV wall box charger is a versatile and reliable charging solution that can be used in various applications, making it an excellent investment for electric vehicle owners and businesses alike.
The AC EV charger is an artwork designed to improve the charging experience with a breakthrough from traditional appearances.
Dynamic LED lights show status by color changes, using a breathing light effect to avoid direct glare.
User-friendly design, specifically engineered for easy installation, maintenance, and daily operation.
Uses J1772/Type 2 connectors that are fully compatible with every electric vehicle on the market.
