China CCS2 To GBT Adapter 400A EV Converter DC Fast Charger Adaptor Suppliers, Factory

400KW CCS2 to GBT Adapter DC Fast Charging Adapter For GBT Chinese Electric Vehicles . 400KW CCS2 to GBT DC Fast Ev Charging Adapter for Chinese Car Zeekr BYD VW ID3 ID4 ID6.

Send Inquiry

Product Description

Specifications

Product Name	CCS Combo 2 to GBT EV Charger Adapter
Rated Voltage	1000V DC
Rated Power	400kW
Application	For Cars with GBT inlet to charge on CCS2 Superchargers
Terminal Temperature Rise	<50K
Insulation Resistance	>1000MΩ (DC500V)
Withstand Voltage	3200Vac
Contact Impedance	0.5mΩ Max
Mechanical Life	No-load plug in/pull out >10000 times
Operating Temperature	-30°C ~ +50°C

Product Features

Safety First: CCS2 to GBT adapter is safe and easy to use for daily charging.

Smart Protection: Built-in thermostat prevents over-heat damage to your car and adapter.

Secure Connection: Self-lock latch prevents accidental plug-off while charging.

High Speed: Max charging speed up to 400kW for ultra-fast performance.

Product Characteristics

Seamless Charging: Enables GBT-compliant EVs and PHEVs to charge at CCS2 DC fast-charging stations without performance loss.
Ultra-High Power: Rated up to 400 kW and 400 A, ideal for high-capacity EV batteries to reduce downtime.
Rugged & Weather-Resistant: IP54-rated design, dust- and splash-resistant, operating from -30°C to +50°C.
Secure & Durable: Dual-end locking mechanism with over 10,000 plug-in/pull-out cycles for long-term use.
Compact & Portable: Lightweight design for easy storage in the trunk, ensuring access to any CCS2 charger.

Product Gallery

400 kW CCS2 to GBT Adapter for Fast Charging

This 400kW CCS2 to GBT EV adapter is the preferred solution for modern electric vehicles. Supporting power up to 400kW, this adapter is designed for CCS2 charging stations in Europe, North America, and Asia, ensuring compatibility, performance, and durability. It is perfect for fleet managers, charging service providers, and EV infrastructure developers worldwide.

The CCS2 to GBT Charging Adapter is compatible with a wide range of models, including BYD, VW ID4/ID6, Geely, NIO, Xpeng, Avatar, Xiaomi, and Zeeker. It connects the charging cable on a CCS2 station to a GB/T vehicle enabled for DC charging. It is very convenient to place this adapter into a car's rear hatch for travel.

Service & Delivery

Delivery Time

• Samples/Test orders: 2-5 working days.
• Standard orders (>100pcs): 7-15 working days.
• Customized orders: 20-30 working days.

Customized Service

• OEM: Color, length, logo, packaging.
• ODM: Appearance design, function setting, new product development.

After Sale Service

• Warranty: One year.
• Replacements or maintenance provided based on specific situations.
• Certified by CE (Europe) and CSA (Canada).

Frequently Asked Questions

Q1: What is the maximum charging power of this adapter? A: The adapter is rated for ultra-fast charging up to 400kW with a maximum current of 400A.

Q2: Which car models are compatible with this CCS2 to GBT adapter? A: It is compatible with a wide range of Chinese GBT EVs, including Volkswagen ID.4/ID.6, BYD, NIO, Xpeng, Geely, Zeeker, and Tesla Model 3/Y (GBT versions).

Q3: Can it be used outdoors in bad weather? A: Yes, it features an IP54-rated design that is dust- and splash-resistant, and it operates effectively between -30°C and +50°C.

Q4: Does the adapter have any safety features to prevent overheating? A: Yes, it includes a built-in thermostat to prevent overheating and a self-locking latch to ensure a secure connection during charging.

Q5: How durable is the mechanical structure of the adapter? A: The adapter is designed for long-term use, capable of withstanding over 10,000 no-load plug-in/pull-out cycles.

Q6: What certifications do these products have? A: All products are certificated by top testing institutions, including CE from Europe and CSA from Canada.
