China Home Level 2 EV Charger 50A 240V App Wifi Smart Car Charging Station Suppliers, Factory

Features: ■ Powerful Performance, Heavy Duty and Outdoor-Ready EV Charging Station ■ Fast Charge ■ Waterproof: IP55 ■ Bluetooth &WiFi Connectivity and Apps ■ OTA Remote Firware Updates Application: ■ Residential Home ■ Multifamily Property ■ Private Property ■ Public Parking Garage ■ Public Commercial Common Area

Send Inquiry

Product Description

Electrical Parameter	32A Max	40A 50A Max
	One phase input: nominal voltage 1×230VAC 50-60 Hz
	7 kW at 1x230VAC	11 kW 12KW at 1x 230 VAC
Input Cord	Hard wired by licensed electrician
Output Cable & Connector	16.4FT/5.0 m cable (26.2FI/8.0m optional)
	IEC62196-2 standard compliance
Smart Grid Connectivity	Built-in Wi-Fi (Optional)(802.11 b/g/n/2.4GHz)/Bluetooth Connectivity
Firmware	Over-the-air (OTA) upgradeable firmware
Environmental Parameter	Dynamic LED lights show charging status: standby, charging in progress, fault indicator, network connectivity
	4.3" LCD Screen
	Protection Class IP65: Weatherproof, dust-tight
	IK08: Resistant polycarbonate case
	Quick-release wall mounting bracket included
	Operating Temperature: -22°F to 122°F (-30°C to 50°C)
Dimension	Main enclosure: 9.7in x 12.8in × 3.8in (300mm × 160mm × 120mm)
Codes & Standards	IEC 61851-1 / IEC 61851-21-2 / IEC 62196-2 compliance, OCPP 1.6
Certification	FCC ETL CE compliance
Energy Management	Home power balancing (Optional)
RFID	Optional
4G Module	Optional
Socket	Optional
Warranty	2 years limited product warranty

⚡ Application Scenarios

1. Residential charging Perfect for homeowners who own a single electric vehicle and want a reliable and convenient way to charge at home. Its compact design and high charging power make it an excellent choice for home use.

2. Workplace charging Can be installed at workplaces, such as offices or factories, to provide employees with a convenient way to charge their electric vehicles while they work.

3. Public charging Ideal for public areas, such as roadside or public parking lots, to provide EV owners with a convenient charging option while out and about.

4. Fleet charging Businesses operating a fleet of electric vehicles can benefit from 7kW, 11KW, or 12KW high power, quickly charging vehicles to keep the fleet productive.

Overall, this single gun smart AC EV wall box charger is a versatile and reliable charging solution that can be used in various applications, making it an excellent investment for electric vehicle owners and businesses alike.

⭐ Key Features

✔

Innovative design: AC EV charger is an artwork designed to improve the charging experience with a breakthrough from traditional appearances.

✔

LED description: The LED light shows charging status by color changes and adopts breathing light to avoid direct glare.

✔

Easy to use: User-friendly design, easy for installation, maintenance, and use.

✔

Compatible with every EV: Uses J1772/Type 2 connector that can charge any EVs on the market.

❓ Frequently Asked Questions

1. What is the maximum charging power of this AC EV Wallbox?

The charger supports various configurations including 7kW (32A), 11kW, and 12kW (up to 50A) at 230VAC.

2. Can this charger be installed outdoors?

Yes, it features an IP65 protection class, making it weatherproof and dust-tight, and an IK08 rated resistant polycarbonate case for durability.

3. Does it support smart monitoring and updates?

Yes, it includes built-in Wi-Fi and Bluetooth connectivity, and supports Over-the-air (OTA) firmware upgrades.

4. What type of electric vehicles is this charger compatible with?

It is compatible with all electric vehicles on the market using IEC62196-2 (Type 2) or J1772 connectors.

5. What is the standard warranty period for this product?

This EV charger comes with a 2-year limited product warranty.

6. Does it provide visual status indicators?

Yes, it features a 4.3" LCD screen and dynamic LED breathing lights that change color to show standby, charging, fault, and network status.
