| Item | Tesla Plug with EV Cable |
| Product Model | MD-TSA-40A, MD-TSA-48A |
| Rated Current | 40A / 48A |
| Operation Voltage | AC 120V / AC 240V |
| Insulation Resistance | >1000MΩ (DC 500V) |
| Withstand Voltage | 2000V |
| Pin Material | Copper Alloy, Silver Plating |
| Shell Material | Thermoplastic, Flame Retardant Grade UL94 V-0 |
| Mechanical Life | No-Load Plug In / Pull Out >10000 Times |
| Contact Resistance | 0.5mΩ Max |
| Terminal Rise | <50K |
| Operating Temperature | -30°C ~ +50°C |
| Impact Insertion Force | >300N |
| Waterproof Degree | IP55 |
| Cable Color | Black, Orange, Green, Blue, etc. |
| Cable Length | (5Meter, 10Meter) The length of the cable can be customized |
| Cable Protection | Reliability of materials, anti-flaming, pressure-resistant, abrasion resistance, impact resistance, and high oil resistance |
| Certification | UL, TUV, CE Approved |
This Tesla Plug with EV Cable supports a rated current of either 40A or 48A and operates at an AC voltage of 120V to 240V.
The plug features excellent internal waterproof protection performance with an IP55 protection grade under working conditions, providing enhanced safety in bad weather.
Yes. While standard cable lengths are 5 meters and 10 meters, the length can be customized. Available standard colors include black, orange, green, blue, and others.
The cable utilizes XLPO for insulation to prolong aging resistance, and a TPU sheath to improve bending life and wear resistance. These materials meet the latest European Union standards.
The Tesla Plug with EV Cable is fully UL, TUV, and CE approved, ensuring compliance with rigorous international safety and quality standards.
Yes, OEM/ODM services are supported, and space is reserved on the plug casing for custom laser logo placement to help you build your brand.
