Best 32A 40A 48A J1772 Type1 EV wallbox EV Charging Station AC EV CHARGER Factory, Factories

Features: ■ Powerful Performance, Heavy Duty and Outdoor-Ready EV Charging Station ■ Fast Charge ■ Waterproof: IP55 ■ Bluetooth &WiFi Connectivity and Apps ■ OTA Remote Firware Updates Application: ■ Residential Home ■ Multifamily Property ■ Private Property ■ Public Parking Garage ■ Public Commercial Common Area

Send Inquiry

Product Description

Technical Specifications

Electrical Parameter	32A Max / 40A 50A Max One phase input: nominal voltage 1×230VAC 50-60 Hz 7 kW / 11 kW 12KW at 1x 230 VAC
Input Cord	Hard wired by licensed electrician
Output Cable & Connector	16.4FT/5.0 m cable (26.2FT/8.0m optional) IEC62196-2 standard compliance
Smart Grid Connectivity	Built-in Wi-Fi (Optional)(802.11 b/g/n/2.4GHz) / Bluetooth Connectivity
Firmware	Over-the-air (OTA) upgradeable firmware
Environmental Parameter	• Dynamic LED lights show charging status • 4.3" LCD Screen • Protection Class IP65: Weatherproof, dust-tight • IK08: Resistant polycarbonate case • Quick-release wall mounting bracket included • Operating Temperature: -22°F to 122°F (-30°C to 50°C)
Dimension	Main enclosure: 300mm × 160mm × 120mm (9.7in × 12.8in × 3.8in)
Codes & Standards	IEC 61851-1/IEC61851-21-2/IEC62196-2 compliance, OCPP 1.6
Certification	FCC ETL CE compliance
Warranty	2 years limited product warranty

Versatile Charging Applications

Residential Charging

Perfect for homeowners with a single electric vehicle seeking a reliable, compact, and high-power home charging solution.

Workplace Charging

Ideal for offices or factories to provide employees with a convenient way to charge while they work.

Public Charging

Can be installed in public parking lots or roadside areas to provide convenient charging for EV owners on the go.

Fleet Charging

Quickly charge business fleets with high power options (7kW/11kW/12kW) to maintain maximum productivity.

Key Innovative Features

Innovative Design

The AC EV charger is a masterpiece designed to break traditional appearances and improve the overall charging experience.

LED Status Indicator

Features breathing light technology to show status via color changes while avoiding direct glare to protect human eyes.

Easy to Use

User-friendly design ensures simple installation, low maintenance, and effortless daily operation.

Universal Compatibility

Equipped with J1772/Type 2 connectors, making it compatible with every electric vehicle currently on the market.

Frequently Asked Questions

Q: What power options are available for this charger?

A: This charger supports various power levels including 7kW, 11kW, and 12kW at 230VAC, with current ratings up to 50A.

Q: Can it be installed outdoors?

A: Yes, it features an IP65 protection class, making it completely weatherproof and dust-tight for outdoor environments.

Q: Does the charger support remote updates?

A: Yes, it is equipped with Over-the-air (OTA) upgradeable firmware to ensure your device always has the latest features.

Q: How do I monitor the charging status?

A: You can monitor status via the 4.3" LCD screen, the dynamic LED indicator lights, or through Wi-Fi/Bluetooth connectivity.

Q: Is it compatible with all electric vehicles?

A: Yes, it uses standard IEC62196-2 / J1772 connectors, ensuring compatibility with all EVs on the market.

Q: What is the warranty period?

A: The product comes with a 2-year limited product warranty for your peace of mind.
