Best Integrated DC Charger 120kW 240kW 360kW 400kW Fast EV Charging Station Factory, Factories

60kw~400kw Integrated DC Charger is a self-contained electric vehicle (EV) charging solution that combines multiple functions like the charging module, charging control, metering, and communication into a single unit, offering fast and efficient DC charging for commercial and public use.

Send Inquiry

Product Description

Item	240kW DC Charger	320kW DC Charger	480kW DC Charger
Input	Input Voltage	3-phase 400V ±15% AC
	Input Voltage Type	TN-S (Three Phase Five Wire)
	Working Frequency	45~65Hz
	Power Factor	≥0.99
	Efficiency	≥94%
Output	Rated Voltage	DC - CHAdeMO 500Vdc; CCS 1000Vdc; GBT 1000Vdc; AC - Type-2 400V; GBT 400V
Output	Max. Output Current	DC - CHAdeMO 125A; CCS 200A; GBT 250A;	AC - Type-2 63A; GBT 32A
Interface	Display	8'' LCD Touchscreen
	Language	Chinese, English, French, German, Spanish, Russian, etc.
	Payment	Mobile APP/RFID/POS
Communication	Network Connection	4G(GSM or CDMA)/Ethernet
Communication	Communication Protocols	OCPP1.6J or OCPP2.0
Working Environment	Working Temperature	-30°C ~ +55°C
	Storage Temperature	-35°C ~ +55°C
	Operating Humidity	≤95% Non-Condensing
	Protection	IP54
	Acoustic Noise	<60dB
	Cooling Method	Forced Air-Cooling
Mechanical	Dimension(W x D x H)	7001900650mm
	No. of Charging Cable	Single	Dual
	Cable Length	5m or 7m
Regulation	Certificate	CE/IEC61851-1/IEC61851-23/IEC61851-21-2

★ Multi-standard Charging

Supports CCS, CHAdeMO, GB/T, and AC connectors. Charging up to 3 vehicles at the same time
Triple outlet ports, two DC cables, one AC cable, and one 3.6kW schuko output
Available in 120kw, 150kw, 160kw, 180kw, 240kw DC Fast Charger Station options.
Ultra High Power CCS 2: 300KW, 360KW, 400KW, 480KW DC Fast Charging Station Station

⚡ High Performance Ultra Fast Charging

Rapid Charger 300 kW Ultra Charging Station and HPC 300kw EV Charging Station DC Fast Charger Piles offer cutting-edge performance. 150kW~300 kW Ultra Fast Charging Stations are ideal for modern infrastructure.

300KW 350KW DC Fast Charging Station is ideal for commercial and public locations.
Significantly reduces waiting times for EV drivers in high-traffic areas.
CCS2 300kW DC Charging Station All-in-One EV Charger Piles.
Charging capacity options up to 480 kW for heavy-duty requirements.

Integrated DC Charger (300kw / 350kw / 400kw)

The Integrated DC charger provides a comprehensive DC charging solution for electric vehicles. This product integrates charging modules, control systems, energy meters, and communication functions.

Flexible configurations: 150kw, 240kw, 300kw, 350kw, 400kw DC Charging Station
Supports CCS, CHAdeMO, GB/T, and Type 2 AC charging
Connectivity: Ethernet, Wi-Fi, 4G connection
Compliance: OCPP 1.6J & OCPP 2.0
Smart charging: Supports dynamic load balancing

● Application Scenarios

1. Urban Public Charging Station: Deployed at public stations serving private cars, commuter vehicles, and buses.

2. Parking Lots and Shopping Malls: Provides convenient charging while customers shop or park.

3. Electricity Business Locations: Suitable for power service centers and dedicated charging hubs.

4. Intercity Highway Charging Station: Ideal for fast charging during long-distance travel.

5. Limited Space Deployment: Rapid deployment and efficient use of available space in constrained environments.

In summary, the 120kW/180kW/240kW/360kW integrated DC chargers are efficient solutions for achieving fast DC charging in various environments, including urban centers, highways, and commercial premises.

Frequently Asked Questions

Q1: Which charging standards do these DC chargers support?

A: Our chargers support multiple global standards including CCS (Combined Charging System), CHAdeMO, GB/T, and Type 2 AC charging.

Q2: Can the station charge more than one vehicle simultaneously?

A: Yes, the system supports multi-standard charging, allowing up to 3 vehicles to be charged at the same time using different outlet ports.

Q3: What is the protection rating for outdoor installation?

A: These units are rated IP54, providing protection against dust and water splashes, making them suitable for various outdoor environments.

Q4: Does the charger support smart network management?

A: Yes, it features Ethernet, Wi-Fi, and 4G connectivity, and fully supports OCPP 1.6J and OCPP 2.0 protocols for remote management and smart charging.

Q5: What are the available payment methods for users?

A: The charger is equipped with an 8'' LCD touchscreen and supports payments via Mobile APP, RFID cards, and POS terminals.

Q6: What is the operating temperature range?

A: The charging stations are designed to operate reliably in extreme conditions, with a working temperature range from -30°C to +55°C.
