Parameters of CCS Type 2 Socket / CCS 2 Inlet
European standard CCS 2 socket are installed on electric vehicles, CCS type 2 inlet. By cooperating with CCS combo 2 DC charging cable, the DC charging function is realized. The products meet IEC 62196.3-2022 and RoHS requirements.
| Model |
CCS 2 socket |
| Rated current |
DC+: 80A, 125A, 150A, 200A, 250A, 300A, 400A; L1/L2/L3/N: 32A; PP/CP: 2A |
| Wire Diameter |
80A/16mm², 125A/35mm², 150A/50mm², 200A/70mm², 250A/95mm², 300A/95mm², 400A/120mm² |
| Rated voltage |
DC+/DC-: 1000V DC; L1/L2/L3/N: 480V AC; PP/CP: 30V DC |
| Withstand voltage |
3000V AC / 1min. (DC + DC- PE) |
| Insulation resistance |
≥ 100mΩ 1000V DC (DC + / DC- / PE) |
| Electronic locks |
12V / 24V optional |
| Mechanical life |
10,000 times |
| Ambient temperature |
-40℃~50℃ |
| Degree of Protection |
IP55 (When not mated), IP44 (After mated) |
| Main Material |
| Shell |
PA |
| Insulation part |
PA |
| Sealing part |
Silicone Rubber |
| Contact part |
Copper alloy |
Introduction Of CCS 2 Socket
EV CHARGING Socket CCS2 FEATURES
Alternating Current
The Combo CCS2 charging socket is available in 350A. It combines alternating current (AC) Type 2 charging and direct current (DC) CCS fast charge in one inlet.
Safe Charging
CCS2 EV sockets are designed with safety insulation on their pinheads to prevent accidental direct contact with human hands, ensuring the highest level of safety.
Investment Value
Built for reliability and longevity, the robust construction ensures this system outlasts competitors, making it an excellent long-term investment.
Market Analysis
Designed for Type 2 connectors common across Europe, ensuring compatibility without the worry of charging standard issues.
Technical Advantages
- Comply with IEC 62196.3-2022 standards
- Rated voltage: 1000V
- Rated current: DC 80A/125A/150A/200A/250A/300A/350A/400A optional; AC 16A, 32A, 63A, 1/3 phase
- 12V/24V electronic lock options available
- Full compliance with TUV/CE certification requirements
- Integrated anti-straight plug dust cover
- Stable temperature rise over 10,000 plugging cycles
- High-quality construction for better durability and service performance
Frequently Asked Questions (FAQ)
What is a CCS Type 2 Socket?
A CCS (Combined Charging System) Type 2 socket is a vehicle inlet that supports both standard AC Type 2 charging and high-speed DC charging through a single interface.
What current ratings are available for this inlet?
The socket supports a wide range of DC current options from 80A up to 400A, and AC current up to 32A or 63A depending on the configuration.
Does this product meet international safety standards?
Yes, it fully complies with IEC 62196.3-2022 standards and meets both TUV and CE certification requirements for European markets.
Is the socket waterproof?
The socket has a protection rating of IP55 when not mated (with cover) and IP44 when mated, providing reliable protection against dust and water splashes.
What is the expected lifespan of the CCS 2 inlet?
The mechanical life is rated for over 10,000 plugging and unplugging cycles, ensuring long-term durability for daily charging needs.
Can I choose the electronic lock voltage?
Yes, we offer both 12V and 24V electronic lock options to match the specific electronic architecture of your electric vehicle.
