| Mode | MQ15 |
| Output voltage | 50VDC ~ 500VDC |
| Output current | 33A |
| Input voltage | 380V ± 15% |
| Input frequency | 50Hz ± 5% |
| Frequency | ≤ 0.1% |
| Ripple voltage | ≤ ± 0.2% (MAX) |
| Efficiency | ≥ 96% (Rated) |
| Power factor | ≥ 0.99 |
| Input current harmonic | ≤ 5% |
| Current-unbalance | ≤ ± 3% |
| Protection | IP23 |
| Communication | GB, CHAdeMO, CCS, Tesla |
| Noise | ≤ 65dB |
| Dimension | 450mm * 300mm * 150mm |
| Weight | 15kg |
This portable charger can charge an EV from 30% SOC to 80% SOC in approximately 120 minutes, depending on the battery capacity.
Yes, by using the optional Tesla adapter, this device can provide high-speed charging for Tesla vehicles via the CHAdeMO interface.
No, this is a portable unit with wheels. It requires no complex installation or commissioning; you can start charging simply by using the screen controls.
The charger operates in temperatures between -20℃ and 45℃. However, it should be protected from direct rain, snow, and direct sunlight to ensure safety and longevity.
The device is programmed to stop charging automatically once the battery State of Charge (SOC) reaches around 80% to protect the battery health.
We provide a 12-month warranty, free installation instructions, and troubleshooting support. Replacement parts are available for free within the warranty period.
