Product Introduction
1. HPC 1000A GB/T EV plug is used in DC fast charging and complies with GB/T 20234.3 standards.
Combined Charging System (GBT) is based on open and universal standards for electric vehicles. Our 1000A HPC GB/T plug is designed for direct-current charging at a maximum of 1000 kW. It is universally compatible, offering high-quality construction designed for over 10,000 charging cycles.
3. 1000A GB/T Connector electric car charging plugs feature integrated temperature sensors (2pcs PT1000) for monitoring temperature changes at the power contacts (between DC+ and DC- terminals). Developed and produced in accordance with the IATF 16949 automotive standard and ISO 9001 standard.
Product Features
-
✓
HPC 1000A GB/T Plug provides convenient charging for Plug-in Hybrid Electric Vehicles (PHEV) and Electric Vehicles (EV).
-
✓
Liquid Cooling 1000A GB/T Gun design utilizes proprietary silver-plated contacts for long-life durability.
-
✓
Supports AC & DC Charging standards of Europe, Asia, Australia, and increasing global standards.
-
✓
Quick-Change DC High Power EV Charging GB/T Connector with EV Cable.
Specification
| Features |
1. Meet GB/T 2023.3-2015 standard
2. Concise appearance, support back installation
3. Back Protection class IP55
4. Max charging power: 1000kW
|
| Mechanical Properties |
1. Mechanical life: no-load plug in/pull out > 10000 times
2. Impact of external force: can afford 1m drop and 2t vehicle run over pressure
|
| Electrical Performance |
1. DC input: 1000A 1000V DC MAX
2. Insulation resistance: > 2000MΩ (DC1000V)
3. Terminal temperature rise: < 50K
4. Withstand Voltage: 3200V
5. Contact resistance: 0.5mΩ Max
|
| Applied Materials |
1. Case Material: Thermoplastic, flame retardant grade UL94 V-0
2. Pin: Copper alloy, silver + thermoplastic on the top
|
| Environmental Performance |
1. Operating temperature: -30°C ~ +50°C |
HPC 600A 800A 1000A GBT Connector DC Liquid Cooling Charging Cable complying with GB/T 20234.3-2023 1000V HPC 1000KW GBT Plug Cable For Supercharger Fast Charging Station.
Frequently Asked Questions
Q1: What is the maximum charging power of the HPC GB/T plug?
The 1000A HPC GB/T connector supports a maximum charging power of 1000kW at 1000V DC.
Q2: How does the connector handle high temperatures during 1000A charging?
The connector is designed with advanced liquid cooling technology and includes two integrated PT1000 temperature sensors to monitor and manage the heat at the power contacts.
Q3: What is the expected durability or lifespan of this charging gun?
It is built for longevity with a mechanical life of over 10,000 no-load plug-in/pull-out cycles and uses silver-plated contacts for enhanced durability.
Q4: Does this product comply with international automotive standards?
Yes, the GB/T connector is developed and produced in accordance with the IATF 16949 automotive standard and ISO 9001 quality management standards.
Q5: Is the connector resistant to external physical damage?
Yes, it is designed to withstand a 1-meter drop and up to 2 tons of vehicle run-over pressure, making it highly robust for public charging environments.
Q6: What is the environmental operating range?
The connector is designed to operate reliably in temperatures ranging from -30°C to +50°C with an IP55 protection class.
